Chapter 3 Troubleshooting

Checking the Access Point LEDs

The LED signals are listed in Table 3-1.

Table 3-1

Access Point LED Signals













Power LED

Alarm LED

2.4 GHz LED

5 GHz LED

Meaning











Off

Off

Off

Off

No power or insufficient power.









Check the power source and ensure that sufficient power is supplied to









the access point. See Low Power Condition, page 3-5.











Off

Red

Off

Off

Power applied and access point powering up (typical 10-20 seconds).









If the red Alarm LED remains on for more than 1 minute, remove power









from the access point and contact TAC for assistance.











All LEDs sequentially cycle on and off



Access point searching for a controller or DHCP server.









If the access point remains in this mode for more than 5 minutes, it is









unable to find the controller. Check the connection between the access









point and the controller. Also verify a DHCP server is available on the









access point subnet.











Green

Off

Blinking

Blinking

Normal operation, both radios transmitting beacons or transmitting and





Yellow

Amber

receiving data packets.









If one or both radio LEDs remain off, this indicates a problem with the









wireless network. Check the controller configuration for the access









point.











Green

Off

On or off

Blinking

Normal operation, 5-GHz radio activity.







Amber

If one or both radio LEDs remain off, this indicates a problem with the

















wireless network. Check the controller configuration for the access









point.











Green

Off

Blinking

On or off

Normal operation, 2.4-GHz radio activity.





Yellow



If one or both radio LEDs remain off, this indicates a problem with the

















wireless network. Check the controller configuration for the access









point.











All LEDs blink on and off simultaneously

Associated to controller and downloading new code.











Off

Blinking

Off

Off

Duplicate access point IP address detected.



red





Advise your network administrator about the problem.



















Off

Off

Off

Off

No power or low power condition.











Blinking

Off

Off

Off

Site survey mode on AIR-AP1010 and AIR-AP1020

Green



















Blinking

Off

Off

Off

Disconnected from root AP on AIR-AP1030.

Green



















Cisco Aironet 1000 Series Lightweight Access Point Hardware Installation Guide

3-4

OL-9403-04





Page 43 Page 45
Image 44
Page 43 Page 45
