Sylvania LD370SC8 S owner manual Trouble Shooting, 5Troubleshooting Guide

Page 42

TROUBLE SHOOTING

5Troubleshooting Guide

If the unit does not perform properly when operated as instructed in this Owner’s Manual, check the following chart once before calling for service.

	Symptom	Remedy

	No power	• Be sure the power cord is plugged in.
		• If a power failure occurs, unplug the power cord for 30 minutes to allow the unit to
		reset itself.
	No picture or sound	• Check if the power is on.
		• Check the outlet connection.
		• Check the antenna or cable connection to the main unit.
		• When the outside antenna is used, check the wire condition and connection.
		• View other TV channels. The problem might be limited to the broadcasting station.
		• Turn off the power and wait for about 1 minute, then turn it on again.
	No color	• Check the antenna or cable connection to the main unit.
		• When the outside antenna is used, check the wire condition and connection.
		• View other TV channels. The problem might be limited to the broadcasting station.
		• Adjust the “Color” in the main menu.
	Sound OK, picture poor	• Check the antenna or cable connection to the main unit.
		• When the outside antenna is used, check the wire condition and connection.
		• Electrical interference from nearby appliances may affect picture quality.
		• Adjust “Contrast” and “Brightness” in the main menu.
		• View other TV channels. The problem might be limited to the broadcasting station.
	Picture distorted	• When the outside antenna is used, check the wire condition and connection.
		• View other TV channels. The problem might be limited to the broadcasting station.
	Weak picture	• Check the antenna or cable connection to the main unit.
		• When the outside antenna is used, check the wire condition and connection.
		• Adjust “Contrast” and “Brightness” in the main menu.
		• View other TV channels. The problem might be limited to the broadcasting station.
T	Lines or streaks in picture	• When the outside antenna is used, check the wire condition and connection.
T		• Electrical interference from nearby appliances may affect picture quality.
		• View other TV channels. The problem might be limited to the broadcasting station.
V	Picture blurred	• When the outside antenna is used, check the wire condition and connection.
		• View other TV channels. The problem might be limited to the broadcasting station.
	Ghosts in picture	• Check the antenna or cable connection to the main unit.
		• When the outside antenna is used, check the wire condition and connection.
		• Electrical interference from nearby appliances may affect picture quality.
		• View other TV channels. The problem might be limited to the broadcasting station.
	Bars on TV screen	• When the outside antenna is used, check the wire condition and connection.
		• Electrical interference from nearby appliances may affect picture quality.

	Picture rolls vertically	• When the outside antenna is used, check the wire condition and connection.
		• Electrical interference from nearby appliances may affect picture quality.
		• View other TV channels. The problem might be limited to the broadcasting station.
	Different color marks on TV	• Move your TV away from nearby electric appliances. Turn off the power and wait 30
	screen	minutes before turning it back on.
		• View other TV channels. The problem might be limited to the broadcasting station.
	Poor reception on some	• Check the antenna or cable connection to the main unit.
	channels	• When the outside antenna is used, check the wire condition and connection.
		• Electrical interference from nearby appliances may affect picture quality.
		• View other TV channels. The problem might be limited to the broadcasting station.
	Picture OK, sound poor	• View other TV channels. The problem might be limited to the broadcasting station.

	No reception of digital signals	• Make sure Autoscan has been completed. (Refer to “Auto Channel Scan” on page 14.)
		Autoscan must be completed when you set up your TV for the first time or move it to
		a location where previously unavailable channels are broadcast.
		• The selected channel may not be broadcasting.
		• When Autoscan is interrupted and not completed, some channels will not be
		received. Make sure to complete. (Refer to “Auto Channel Scan” on page 14.)

42

EN
