Connections

Connecting to USB		Connecting a Digital Camcorder

Using the USB input connector, you can use a USB memory stick as the playable media.

JPEG, MP3 and DivX media files can be played from USB memory.

•Only MP3 Player (or Digital Camera) which doesn’t need to install Driver software are available for this DVB-T VCR/DVD Recorder.

•It is impossible to copy the JPEG or MP3 file in a Digital camera or mp3 player to the DVD or VCR.

MP3 Player or Digital Camera

Front of DVB-T VCR/DVD Recorder

Using the front panel DV IN jack, it is possible to connect a DV digital camcorder, video deck or DVD+R/RW recorder and digitally transfer DV tapes or DVD+R/RW discs to DVD±R or DVD±RW .

Use a DV cable (not supplied) to connect the DV In/Out jack of your DV camcorder/video deck to the front panel DV IN jack of the DVB-T VCR/DVD Recorder.

This jack is for connection to DV equipment only. It is not compatible with digital satellite tuners or D- VHS video decks.

DV Digital Camcorder

DV

IN/OUT

DV IN

Front of DVB-T VCR/DVD Recorder

20
