Page 37

Hard Disk Recorder

Your receiver is equipped with a hard disk and therefore allows for the recording of the current programme while watching the same one time delayed, or another earlier recorded programme. The recording ca- pacity is depended on the picture contents of the programmes broad- cast.

Mind the information on the next operation steps in the bar at the bottom of the screen insert!

Recording

Hard Disk Capacity

Please check before each recording whether the hard disk still has enough capacity. By pressing , or ,

the contents on the hard disk (1) as well as the remaining storing ca- pacity (2) are displayed.

Instantly Recording (OTR/One Touch Recording)

(1)

(2)

You can immediately record the current programme on the hard disk with your DVB-T recorder. To do so, merely press () (OTR = One Touch Recording/Instant recording) and confirm with .

Recording Manually

Press and  to select a programme and prepare the recording with the red key ().

Now a menu is displayed showing the channel name, the programme title (information) – if broadcast - as well as the starting time and the end of the programme. You can vary the name and information and

the recording stop with the number keys. Press  to vary the recording stop in 30 min steps.

Press to start the recording.

The 'hard disk contents' displayed now for a few seconds show a red 'R' for Record in the right upper corner of the screen, and display the title of the current programme in the small box at the bottom. For a few seconds, the LED indicates 'REC' (Record) and 'HXXX', the record

37
