Macros
The MACRO button, in conjunction with digits 1 through 8, lets you to program and store up to 8 sequences of IR Commands
To Setup a Macro
1.Press and hold the SETUP button until CODE SETUP is displayed (takes about 3 seconds), then release the SETUP button.
2.Press the down navigation button until MACRO SETUP is displayed. Press and release OK.
3.MACRO SET is displayed. Press and release OK.
4.MACRO KEY? is displayed. Press and release digit button 1 thru 8 where you want to store the Macro.
5.MACRO X MODE? (where “X” is 1, 2, …, 7, 8) is displayed. Press and release the desired Mode button (TV, VCR, DVD, etc.). The first button in a Macro sequence must always be a Mode button.
6.MACRO X KEY? is displayed along with the button count (initially 02). Press and release the buttons you want to be included in the Macro, in the order you want them to be sent (up to 20).
7.To store the Macro at any point, press and release the Macro button. Note the Macro will be stored automatically on the 20th button press.
8.SUCCESS is displayed and the remote exits Setup Mode and returns to normal operation.
MACRO
button
24
Macros, cont.
In normal operation, to activate the Macro press and release the MACRO button followed (within 20 seconds) by the digit button 1 thru 8. MACRO X is displayed while the Macro sequence is being carried out then remote returns to normal operation. If no Macro is stored under the chosen digit key then MACRO X VOID is briefly displayed
and the remote returns to normal operation.
Macro Notes
1.You might want to add “delays” in a Macro sequence (e.g. to allow for your TV
2.There is an automatic delay of half a second between each IR transmission in a Macro sequence.
3.* The first button in a Macro sequence MUST be a Mode button (TV, VCR, etc.).
4.Setup and Macro buttons cannot be included in a Macro.
5.Press SETUP to quit Macro Setup.
To Delete a Macro
1.Press and hold the SETUP button until CODE SETUP is displayed (takes about 3 seconds), then release the SETUP button.
2.Press the down navigation button until MACRO SETUP is displayed. Press and release OK.
3.Press the down navigation button until MACRO CLEAR is displayed. Press and release OK.
4.MACRO KEY? is displayed. Press and release digit key 1, 2, …7 or 8 for the Macro you want to delete.
5.CONFIRM CLEAR is displayed. Press and release OK.
6.PLEASE WAIT is briefly displayed and the remote exits Setup Mode and returns to normal operation.
25
