How to use OSD Menu
es
HIGH. As you adjust it from HIGH to LOW, the screen switches to black and white mode under the darker situation.
DWELL TIME of DAYÆNIGHT sets the time to maintain switched black and white mode.
The BRIGHTNESS of NIGHTÆDAY sets the brightness degree of BW to color switching, for which you can select from LOW, MID, and HIGH. As you adjust it from HIGH to LOW, the screen switches to color mode under the darker situation.
DWELL TIME of NIGHTÆDAY sets the time to maintain switched color mode.
The MASK AREA menu is used to prevent unintended mode switching or inability of determining the switching due to existence of high spot light source at night.
If you press the SETUP switch in item 1 or 2 of the MASK AREA menu, you will see a menu where you can specify an area to MASK.
MASK AREA
<SIZE> <LOCATION>
The MASK is only for determining the mode switching, and any excessive bright area at night will be excluded by the configured MASK.
Note :
–If BACKLIGHT is set to BLC, the MASK AREA function will be deactivated.
•DAY
This enables an auto switch between DAY and NIGHT mode using the interface with the external sensor.
❖ WHITE BAL | [DAY/NIGHT] |
If you want to adjust the color scheme, use the WHITE BALANCE function.
•DAY
In DAY mode, you can set the color values of RED and BLUE. The screen will be displayed in colors according to your settings.
WHITE BAL
DAY/NIGHT |
|
| DAY | |
MODE |
| AWC | ||
RED | ||||
BLUE | ||||
|
|
|
|
|
| [0248] |
|
|
|
|
|
| ||
[0247] |
|
|
| |
ENG |
e.
|
You can specify MASK 1 and 2 simultaneously.
Note :
–You can set the values of
English – 21
