Electrolux EWW 168543 W Automatic Drying icons, Extra rinse icon Selected drying time value

Page 7

Rinse Hold: the water of the last rinse is not emptied out to prevent the fabrics from creasing. At the end of the programme on the display the icon 2.8 is still on: the door is locked to indicate that the water must be emptied out.

Night Cycle: the machine will not drain the water of the last rinse, so as not to wrinkle the laundry. As all spinning phases are sup- pressed, this washing cycle is very noise- less and it can be selected at night or in times with a more economical power rate. On some programmes the rinses will be performed with more water. At the end of the programme on the display the icon 2.8 is still on: the door is locked to indicate that the water must be emptied out. To empty out the water, please read the paragraph «At the end of the programme».

2.5: Automatic Drying icons

By pressing the button 5 you can choose one of the required degree of drying for Cottons and Synthetics:

= Extra dry (for Cottons)

= Store dry (for Cottons and Synthet- ics)

= Iron dry (for Cottons)

When an automatic drying is performed, the message AUTOcomes on.

2.6: Extra rinse icon .

2.7: Selected drying time value

The drying time is displayed in minutes or in hours and minutes. After the programme has started the time remaining is updated every minute.

2.8: Door locked icon

After the programme has started, this icon is lighted on. When the programme has fin- ished, this icon disappears. The door can be opened.

2.9: Child safety lock (see «Personali-

sation» paragraph).

2.10: Delay icon

This icon illuminates when you set the delay start.

2.11 (Values)

Duration of the selected programme The duration is calculated automatically on the basis of the maximum recommen- ded load for each type of fabric. The du- ration is displayed in hours and minutes.

electrolux 7

The time remaining is updated every mi- nute.

End of programme

When the programme has finished three flashing zeros 0.00 are displayed. The light of button 8 is off.

Incorrect option selection

If an option not compatible with the set wash programme is selected, the mes- sage Err is displayed for a few seconds. The integrated red light of button 8 flash- es.

Alarm codes

Some alarm codes are displayed in the event of operating problems (see para- graph «What to do if... »).

Delay Time value

The selected delay appears on the dis- play for a few seconds then the duration of the previously set programme is dis- played. The delay time value decreases by one unit every hour and then. When 1

hour remains, the time decreases every minute.

2.12: Soil degree icons

Intensive

Normal

Daily

Light

Quick

Super Quick

Refresh

Super Refresh

When you set a programme on the display appears an icon indicating the degree of soiling automatically proposed by the ma- chine.

2.13: Clock icon

The duration of the set programme is dis- played by the animation of the clock icon.

2.14: Drying programme phase icons

= Drying

= Anti-crease

When you set the drying programme, all drying phase icons are shown. When the programme has started, the only icon of the running phase stays on.

2.15: Washing programme phase icons

Prewash

Wash

Rinses
