American Dryer Corp T20 manual Electrical Service Specifications Gas Models Only, T30, T50, T75

Page 18

Warning (Gas Models Only)

!Dryers built for use with a voltage between 200 and 240 must verify the input voltage during

installation. If the nominal voltage is outside of the medium tolerances shown on the diagram below, adjust the autotransformer, located

near the burner assembly.

To adjust the

TERM

LINE VOLTAGE

autotransformer wiring,





50 Hz

60 Hz



place the red wire on the







HIGH

260

283

appropriate tap (HIGH, MED,

226

249

LOW) of the











239

260

autotransformer. For

MED

208

230

additional wiring details,



refer to the electrical

LOW

217

236

diagram located on the

189

208



inside of the control panel.













Electrical Service Specifications

Gas Models Only

ELECTRICAL SERVICE SPECIFICATIONS

IMPORTANT: 208 VAC AND 230/240 VAC ARE NOT THE SAME. When ordering, specify exact voltage.

NOTES:

A.

When fuses are used they must be dual element, time delay, current limiting,





class RK1 or RK5 ONLY. Calculate/determine correct fuse value, by applying





either local and/or National Electrical Codes to listed appliance amp draw data.



B.

Circuit breakers are thermal-magnetic (industrial) motor curve type ONLY.





For others, calculate/verify correct breaker size according to appliance amp





draw rating and type of breaker used.



C.

Circuit breakers for 3-phase (3ø) dryers must be 3-pole type.

SERVICE



WIRE

APPROX.

CIRCUIT

PHASE

AMP DRAW

VOLTAGE

SERVICE

BREAKER



60 Hz

50 Hz













T20







120

2

8.9

15

200

2

7.7

7.8

15

208

2

7.6

15

220

2

7.4

15

230

2

7.3

15

240

2

7.2

7.0

15





T30







120

2

10.3

15

200

2

8.7

8.8

15

208

2

8.4

15

220

2

8.1

8.1

15

230

2

7.4

15

240

2

7.7

7.0

15





T50







120

2

15.6

20

200

2

10.5

20

208

2

10.5

20

220

2

10.0

10.7

20

230

2

10.8

20

240

2

9.7

20





T75







120

2

15.6

20

200

2

10.5

20

208

2

10.5

20

220

2

10.0

10.7

20

230

2

10.8

20

240

2

9.7

20

7/15/08

Steam Models Only

ELECTRICAL SERVICE SPECIFICATIONS

IMPORTANT: 208 VAC AND 230/240 VAC ARE NOT THE SAME. When ordering, specify exact voltage.

NOTES:

A.

When fuses are used they must be dual element, time delay, current limiting,





class RK1 or RK5 ONLY. Calculate/determine correct fuse value, by applying





either local and/or National Electrical Codes to listed appliance amp draw data.



B.

Circuit breakers are thermal-magnetic (industrial) motor curve type ONLY.





For others, calculate/verify correct breaker size according to appliance amp





draw rating and type of breaker used.



C.

Circuit breakers for 3-phase (3ø) dryers must be 3-pole type.

SERVICE



WIRE

APPROX.

CIRCUIT

PHASE

AMP DRAW

VOLTAGE

SERVICE

BREAKER



60 Hz

50 Hz













T30







120

2

9.3

15

208

2

6.2

6.0

15

220

2

5.6

5.5

15

230

2

5.4

15

240

2

5.1

15





T50







120

2

14.4

20

200

2

8.2

20

208

2

8.2

20

220

2

7.8

8.4

20

230

2

8.5

20

240

2

7.6

20





T75







120

2

14.4

20

200

2

8.2

20

208

2

8.2

20

220

2

7.8

8.4

20

230

2

8.5

20

240

2

7.6

20

7/15/08

NOTES ______________________________________________________

_____________________________________________________________

_____________________________________________________________

_____________________________________________________________

_____________________________________________________________

_____________________________________________________________

_____________________________________________________________

_____________________________________________________________

_____________________________________________________________

_____________________________________________________________

_____________________________________________________________

_____________________________________________________________

_____________________________________________________________

_____________________________________________________________

_____________________________________________________________

18

JLA Limited

113429 - 9
