Pride Mobility SC4401, SC4001 manual F E T Y G U I D E L I N E S

Page 2

S A F E T Y G U I D E L I N E S

WARNING! An authorized Pride Provider or qualified technician must perform the initial setup of this scooter and must perform all of the procedures in this manual.

The symbols below are used throughout this owner's manual and on the scooter to identify warnings and important information. It is very important for you to read them and understand them completely.

WARNING! Indicates a potentially hazardous condition/situation. Failure to follow desig- nated procedures can cause either personal injury, component damage, or malfunction. On the product, this icon is represented as a black symbol on a yellow triangle with a black border.

MANDATORY! These actions should be performed as specified. Failure to perform man- datory actions can cause personal injury and/or equipment damage. On the product, this icon is represented as a white symbol on a blue dot.

PROHIBITED! These actions are prohibited. These actions should not be performed at any time or in any circumstances. Performing a prohibited action can cause personal injury and/or equipment damage. On the product, this icon is represented as a black symbol with a red circle and a red slash.

INTENDED USE

The intended use of the Pride Mobility Products device is to provide mobility to persons limited to a seated position that have the capability of operating a scooter.

Please fill out the following information for quick reference:

Pride Provider:__________________________________________________________________

Address: _______________________________________________________________________

Phone Number:__________________________

Purchase Date: __________________________ Serial Number:_________________________

NOTE: This owner’s manual is compiled from the latest specifications and product information avail- able at the time of publication. We reserve the right to make changes as they become necessary. Any changes to our products may cause slight variations between the illustrations and explanations in this manual and the product you have purchased. The latest/current version of this manual is available on our website.

Copyright © 2012

Pride Mobility Products Corp.

INFMANU2995/Rev E/February 2012
