Lincoln Electric IM869-D manual Accessories, K1690-1 Gfci Receptacle KIT

Page 19

C-1

ACCESSORIES

C-1







K930-2 TIG Module - Provides high frequency plus a gas valve for TIG welding. A water valve is available as an option. Requires 115 volt AC input. (Limited to 250A - 60% Duty Cycle).

K802-D Power Plug Kit - Kit includes male plug for 20 amp receptacle.

K2641-1 Trailer - A 4-wheel steerable trailer for in- plant and yard towing with E78-14 load range (B) tube- less tires. Mounts directly to welder base. (Not for use on the road.) Comes standard with a Duo-Hitch™, a 2” Ball and Lunette Eye combination hitch.

K2637-1 Trailer - A 2-wheel trailer designed for road(1), off road, in-plant and yard towing. Trailer mounts directly to welder base. Comes standard with a Duo- Hitch™, a 2” Ball and Lunette Eye combination hitch.

Order:

K2636-1 Trailer

K2639-1 Fender & Light Kit

K2640-1 Cable Storage Rack

1For highway use, consult applicable federal, state and local laws regarding possible requirements for brakes, lights, fenders, etc.

WARNING

Pipe Thawing with an arc welder can cause fire, explosion, damage to electric wiring or to the arc welder if done improperly. The use of an arc welder for pipe thawing is not approved by the CSA, nor is it recommended or supported by Lincoln Electric.

------------------------------------------------------------------------

K704 Standard Accessory Kit - Includes electrode and work cables, headshield, work clamp and elec- trode holder.

K385-[ ] CV Adapter - Provides constant voltage out- put for semiautomatic welding. (Field installation only).

K1690-1 GFCI RECEPTACLE KIT

Includes one UL approved 120V ground fault circuit interrupter duplex type receptacle with cover and installation instructions. Replaces the factory installed

120V duplex receptacle. Each receptacle of the GFCI Duplex is rated at 20 Amps, the maximum total current

from the GFCI Duplex is limited to the 20 Amps. Two kits are required. See the MAINTENANCE section for detailed information on testing and resetting the GFCI receptacle.

K1735-1MULTI-WELD 350 - For multiple arcs from the DC output of a welding power source. See bulletin E5.300 for Multi-Weld 350 and distribution system.

K2144-1 Oil Drain Kit- Includes ball valve, hose and clamp.

K1858-1 Service Indicator Kit- Provides a GO / NO-GO visual indication of air cleaner element useful service life. Filter service based on restriction readings allows the longest life possible from the filter and best engine protection.

SAE-400
