Delta DLKC6580V2-1 instruction manual Hazard

Page 3

IMPORTANT SAFETY INSTRUCTIONS

Save these instructions

Improper operation or maintenance of this product could result in serious injury and property damage. Read and understand all warnings and operation instructions before using this equipment.

HAZARD

WARNING: Risk of explosion or fire

What Could Happen

It is normal for electrical contacts within the motor and pressure switch to spark.

If electrical sparks from compressor come into contact with flammable vapors, they may ignite, causing fire or explosion.

Restricting any of the compressor venti- lation openings will cause serious over- heating and could cause fire.

Unattended operation of this product could result in personal injury or prop- erty damage. To reduce the risk of fire, do not allow the compressor to operate unattended.

How To Prevent It

Always operate the compressor in a well ventilated area free of combustible materials, gasoline, or solvent vapors.

If spraying flammable materials, locate compressor at least 20 feet away from spray area. An additional length of hose may be required.

Store flammable materials in a secure location away from compressor.

Never place objects against or on top of compressor. Operate compressor in an open area at least 12 inches away from any wall or obstruction that would restrict the flow of fresh air to the ventila- tion openings.

Operate compressor in a clean, dry well ventilated area. Do not operate unit indoors or in any confined area.

Always remain in attendance with the product when it is operating.

Always disconnect electrical power by moving pressure switch lever to the off position and drain tank daily or after each use.

3-ENG

D26161

Page 2 Page 4
Image 3
Page 2 Page 4
Contents Instructio N M Anual Safety Guidelines Definitions Hazard Attachments & Accessories Hazard What can Happen HOW to Prevent IT Fire, Inhalation, Damage to Vehicle Surfaces Duty Cycle SpecificationsAccessories GlossaryTo Add Oil To Pump AssemblyTools Required for Assembly UnpackingInstallation Location of the Air CompressorAnchoring of the Air Compressor Air Distribution System Wiring InstructionsTypical Compressed AIR Distribution System Know Your Air Compressor Description of Operation OperationHow to Use Your Unit Before Starting Break-in ProcedureHow to Stop Before Each Start-Up How to StartMaintenance To Check Safety ValveCustomer Responsibilities Changing To Drain TankOil CheckingAir Filter Inspection and Replacement Belt ReplacementAdjusting Belt Tension Air compressor Head Bolts Torquing Motor Pulley/Flywheel AlignmentAir Compressor Pump Intake and Exhaust Valves Inspect Air Lines and Fittings for LeaksTo Replace or Clean Check Valve Service and AdjustmentsAdditional Service StorageMotor Problem Cause Correction TroubleshootingPressure reading Minal box area 25-ENG D26161 AIR Compressor Diagram KEY Part Number Description Parts ListPump Diagram Not Shown Limited Warranty
