Samsung AR12FSFTJWQNET, AR09FSFTKWQNET, AR12FSFTKWQNET, AR09FSFTJWQNET, AR09HSFTKWQNET manual Contents

Featuresofyournewairconditioner Contents

Cool Summer Offer

On those hot sweltering summer days and long restless nights, there is no better escape from the heat than the cool comforts of home. Your new air conditioner brings an end to exhausting hot summer days and lets you rest. Beat the heat with your own air conditioner this summer.

Cost Efficient System

Your new air conditioner not only provides maximum cooling power in the summer, but also can be an efficient heating method in the winter with the advanced“Heat pump”system.“Heat pump”system is 3 times more efficient compare to the other electrical heating appliance, so you can further reduce its running cost. Now, meet year- round needs with one air conditioner.

USING PARTS
Safety precautions	3
Checking before use	10
Checking the name of the parts	11
Checking the remote controller	12
Basic function	14
Adjusting the air flow direction	16
Using the Turbo function	16
mode	17
Setting the On/Off timer	18
Using the Smart Saver function	19
Using the Quiet function	20
Using the Auto Clean function	20
Cleaning the air conditioner	21
Maintaining the air conditioner	23
Troubleshooting	24

Look for Everywhere

The elegant and harmonious design gives priority to the esthetics of your space and complements any of your existing interior décor. With its soft color and rounded-edge shape, the new air conditioner adds class to any room. Enjoy what your air conditioner offers both functionally and esthetically.

function

function allows you to set a comfortable sleep temperature while saving energy and having sound sleep.

INSTALLATION PARTS
Safety precautions	26
Choosing the installation location	27
Accessories	30
Fixing the installation plate	30
Connecting the assembly cable	32
Installing and connecting the assembly
pipe of the indoor unit	34
Purging the indoor unit	35
Cutting or extending the pipe	35
Installing and connecting the
drain hose of the indoor unit	36
Changing direction of the drain hose	37
Installing and connecting the
drain hose of the outdoor unit	38
Purging the connected pipes	38
Performing the gas leak tests	41
Fixing the indoor unit in place	42
Fixing the outdoor unit in place	42
Final check and trial operation	43
Pump down procedure
(when removing the product)	43
How to connect your extended power cables	44
Sub PCB installation(optional)	45

This product has been determined to be in compliance with the Low Voltage Directive (2006/95/EC) and the Electromagnetic Compatibility Directive (2004/108/EC) of the European Union.

Correct Disposal of This Product

(Waste Electrical & Electronic Equipment)

(Applicable in countries with separate collection systems)

This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate these items from other types of waste and recycle them responsibly to promote the sustainable reuse of material resources. Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and how they can take these items for environmentally safe recycling.

Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and its electronic accessories should not be mixed with other commercial wastes for disposal.
