Emerson 848T Table D-6. Input Selector Function Block Parameters, IN1 IN2 IN3 IN4 IN5 IN6 IN7

Page 105

Reference Manual

00809-0100-4697, Rev EA October 2011

Rosemount 848T

INPUT SELECTOR FUNCTION BLOCK

The Input Selector (ISEL) function block can be used to select the first good, Hot Backup, maximum, minimum, or average of as many as eight input values and place it at the output. The block supports signal status propagation. There is process alarm detection in the Input Selector function

IN_1

IN_2

IN_3

IN_4

IN_5

IN_6

IN_7

IN_8 DISABLE_1 DISABLE_2 DISABLE_3 DISABLE_4 DISABLE_5 DISABLE_6 DISABLE_7 DISABLE_8

OP_SELECT

OUT

OUT_D

SELECTED

ISEL

block. Table D-6lists the ISEL block parameters and their descriptions, units of measure, and index numbers. The block execution time is 30 ms.

IN (1-8) = Input

DISABLE (1-8) = Discrete input used to disable the associated input channel

SELECTED = The selected channel number

OUT = The block output and status

OUT_D = Discrete output that signals a selected alarm condition

Table D-6. Input Selector Function Block Parameters

Number

Parameter

Units

Description

1

ST_REV

None

The revision level of the static data associated with the input selector block. The







revision value will be incremented each time a static parameter value in the block







is changed.

2

TAG_DESC

None

The user description of the intended application of the block.

3

STRATEGY

None

The strategy field can be used to identify groupings of blocks. This data is not checked







or processed by the block.

4

ALERT_KEY

None

The identification number of the plant unit. This information may be used in the host for







sorting alarms, etc.

5

MODE_BLK

None

The actual, target, permitted, and normal modes of the block.







Actual: The mode the “block is currently in”







Target: The mode to “go to”







Permitted: Allowed modes that target may take on







Normal: Most common mode for target

6

BLOCK_ERR

None

This parameter reflects the error status associated with the hardware or software







components associated with a block. It is a bit string, so that multiple errors may







be shown.

7

OUT

OUT_RANGE

The primary analog value calculated as a result of executing the function block.

8

OUT_RANGE

EU of OUT

The engineering units code to be used in displaying the OUT parameter and







parameters which have the same scaling as OUT.

9

GRANT_DENY

None

Options for controlling access of host computers and local control panels to operating,







tuning, and alarm parameters of the block. Not used by device.

10

STATUS_OPTS

None

Allows the user to select options for status handling and processing.

11,1 2, 13,

IN_(1, 2, 3, 4, 5,

Determined by

A connection input from another block

14, 25, 26,

6, 7, 8)

source



27, 28







D-15
