Preparation

Clearances

Allow the following clearances for ease of installation, proper air circulation and plumbing and electrical connections:

Sides	19 mm (3/4″)
Top	25 mm (1″)
Back	25 mm (1″)

If Model 19, 22, or 25 is to be installed against a wall on the hinge side, allow 44 mm (13⁄4 ″) for door clearance.

Water Supply to Icemaker (on some models)

If your refrigerator has an icemaker, or if you plan to add an icemaker later, the icemaker will have to be connected to a cold drinking water line.

A water supply kit containing copper tubing, shutoff valve, fittings and instructions is available at extra cost from your local distributor. There should be sufficient tubing from the cold water supply to the icemaker inlet to allow moving the refrigerator out from the wall several feet [approximately 244 cm (8′) of 1/4″ copper tubing in three 25 cm (10″) diameter coils].

Do not use kits with plastic tubing since there is water pressure in the supply line at all times.

Maximum permissible inlet water pressure—8.3 bars (120 p.s.i.).

Minimum permissible inlet water pressure—1.4 bars (20 p.s.i.).

Installation of icemaker must be made by a qualified service technician.

Rollers

Some models have adjustable rollers that allow you to move the refrigerator away from the wall for cleaning. Rollers should be set so the refrigerator is firmly positioned on the floor and the front is raised just enough [about 19 mm (3/4″) from the floor] that the doors close easily when opened about halfway.

Remove the base grille by grasping the bottom of the grille and pulling it out.

Turn the two front roller adjusting screws clockwise to raise the refrigerator, counterclockwise to lower it.

To replace the base grille, line up the clips on the back of the grille with the openings in the base plate and push the grille forward until it snaps into place.

When You Go on Vacation

For shorter vacations, remove perishable foods and leave controls at regular settings. However, if room temperature is expected to drop below 16°C (60°F), follow the same instructions as for extended vacations.

For extended vacations or absences, shut off the power to the refrigerator, move the fresh food control to the “0” position, and clean the interior with a baking soda solution of 15 ml (1 tablespoon) of baking soda to one liter (1 quart) of water. Wipe dry. To prevent odors, leave an open box of baking soda in the refrigerator. Leave doors open.

Move icemaker feeler arm to STOP (up) position and be sure to shut off water supply to the refrigerator.

When You Move

Disconnect power cord from wall outlet, remove all food, and clean and dry the interior.

Secure all loose items such as grille, shelves and storage pans by taping them securely in place to prevent damage.

Be sure refrigerator stays in upright position during actual moving and in van. Refrigerator must be secured in van to prevent movement. Protect outside of refrigerator with blanket.

Dimensions

Model	18	19	21	22	24	25
A*	163 cm (64″)	163 cm (64″)	168 cm (661⁄4″)	168 cm (661⁄4″)	170 cm (67″)	170 cm (67″)
B	75 cm (293⁄8″)	75 cm (293⁄8″)	79 cm (311⁄4″)	79 cm (311⁄4″)	88 cm (341⁄2″)	88 cm (341⁄2″)	A
C**	80 cm (311⁄2″)	83 cm (323⁄4″)	80 cm (311⁄2″)	83 cm (323⁄4″)	80 cm (311⁄2″)	83 cm (323⁄4″)
D	147 cm (58″)	147 cm (58″)	152 cm (597⁄8″)	152 cm (597⁄8″)	160 cm (627⁄8″)	160 cm (627⁄8″)
E	70 cm (273⁄4″)	70 cm (273⁄4″)	70 cm (273⁄4″)	70 cm (273⁄4″)	70 cm (273⁄4″)	70 cm (273⁄4″)
* Height does not include hinge—Add 22 mm (7/8″)for hinge.
* Height does not include hinge—Add 22 mm (7/8″)for hinge.
** Depth includes handle.							C
