LG Electronics GR-P227/L227 Parts Identification, Freezer Refrigerator compartment compartment

Page 8

PARTS IDENTIFICATION

1. Ref No. : GR-P227/GR-P257(INTERNAL FILTER)

Frame Display

Dispenser Lamp

Ice & Water

Dispenser Button

Cover PWB

Water Tube

Home Bar

Freezer Refrigerator compartment compartment

Automatic Icemaker

Shelf

Lamp

Shelf

Drawer

Door rack

Drawer

Door rack

Lower cover

Milk product corner

Lamp

Door Rack

Shelf

Can Server (Optional)

Wine holder (Plastic or wire)

Refreshment center(Optional)

Shelf (Folding or Normal)

Egg Box

Vegetable Drawer

Humidity Switch

Miracle Zone (Optional) Fresh compartment (Optional)

Door Rack

Conversion switch (Meats/Vegetables) (Optional)

- 6 -
