EM-120SM —TROUBLESHOOTING (ENGINE)

Practically all breakdowns can be prevented by proper handling and maintenance inspections, but in the event of a breakdown, please take a remedial action following the

diagnosis based on the Engine Troubleshooting (Table 3) information shown below and on the proceeding page. If the problem cannot be remedied, please leave the unit just as it is and consult our company's business office or service

TABLE 3. ENGINE TROUBLESHOOTING

	SYMPTOM	POSSIBLE PROBLEM	SOLUTION

		Inspect carburetor to see if fuel	Check fuel line
		is reaching it?

		No Fuel?	Add Fuel

		Water in fuel tank?	Flush or replace fuel tank.

		Fuel filter clogged?	Replace fuel filter

		Stuck carburetor?	Check float mechanism.
	Poor starting
	Poor starting	Spark plug is red?	Spark plug is fouled. Check tranistor ignition unit.

		Spark plug is blue-white?	Insufficient compression, injected air leaking. Carburetor jets are
		Spark plug is blue-white?	clogged (overflow).
			clogged (overflow).

		No spark present at tip of spark	Tranistor ignition unit broken, high voltage cord cracked or broken.
		plug?	Start/Stop switch broken. Replace spark plug if fouled.

		No oil?	Add oil as required.

		Oil pressure alarm lamp blinks	Check Automatic shutdown circuit "oil sensor".
		upon starting?	Check Automatic shutdown circuit "oil sensor".
		upon starting?

		Engine will not turn over?	Replace cylinder and piston and if necessary axel joint.

		Cylinder head connecting bolts	Tighten cylinder head connecting bolts.
		loose?	Tighten cylinder head connecting bolts.
		loose?

	Insufficient power output "no	Cylinder head gasket damaged?	Replace cylinder head gasket.
	compression"
	compression"	Malfunction of valve seat?	Re-seat valves.
		Malfunction of valve seat?	Re-seat valves.

		Spark plug is loose?	Replace spark plug.

		Worn piston rings?	Replace piston rings.

		Malfunction in air-cleaner system,	Clean or replace air filter.
		air filter clogged?	Clean or replace air filter.
		air filter clogged?

		Air leaking in from interface	Tighten bolts between carburetor and cylinder head. Replace
	Insufficient power output	between carburetor and cylinder	cylinder head gasket.
	"compression"	head?

			Clean or replace fuel filter.
		Malfunction in fuel system?	Clean or replace carburetor.
			Check carburetor float.

PAGE 20 — ESSICK EM-120SM— OPERATION AND PARTS MANUAL — REV. #5 (03/29/10)

Image 20
