Cub Cadet Ex32002 Ex Series, Cylinder Head & Valve Cover, Copyright 2007 Cub Cadet Yanmar LLC

Ex Series			9		Ex3200
		FIG 4. CYLINDER HEAD & VALVE COVER
	REF
	NO.	PART NUMBER	DESCRIPTION	QTY
	1	CY-129004-11241	SHAFT ASSY, ROCKER	1
	2	CY-129004-11251	SHAFT, ROCKER ARM	1
	4	CY-119802-11260	SUPPORT, ROCKER ARM	2
	5	CY-119802-11270	SUPPORT, ROCKER ARM	2
	6	CY-119802-11280	STUD, 8X18	3
	7	CY-129150-11280	SPRING	3
	8	CY-129004-11650	ARM ASSY, ROCKER	6
	9	CY-129150-11230	SCREW, VALVE	6
	11	CY-129150-11750	NUT M8XP1.0	6
	12	CY-129150-11370	CAP, VALVE	6
	13	CY-129008-11700	HEAD ASSY, CYLINDER	1
	16	CY-120130-11860	GUIDE, VALVE	3
	18	CY-129150-11810	GUIDE, VALVE	3
	20	CY-27241-400000	PLUG 40	2
	21	CY-129005-11100	VALVE, INTAKE	3
	22	CY-129100-11112	VALVE, EXHAUST	3
	23	CY-129795-11120	SPRING, VALVE	6
	24	CY-129795-11180	RETAINER, SPRING	6
	25	CY-121400-11340	SEAL, VALVE STEM	3
	26	CY-124460-11340	SEAL, VALVE STEM	3
	27	CY-27310-080001	COTTER 8	6
	29	CY-119802-11870	PROTECTOR, NOZZLE	3
	30	CY-119625-11880	SEAT, NOZZLE	3
	31	CY-129004-11900	RETAINER, NOZZLE	3
	32	CY-120270-54410	WASHER	3
	33	CY-22351-060012	SPRING PIN 6X12	2
	34	CY-26106-080252	BOLT M 8X 25 PLATED	2
	35	CY-26106-080352	BOLT M 8X 35 PLATED	3
	36	CY-26106-080502	BOLT M 8X 50 PLATED	6
	37	CY-129055-11350	COVER ASSY, VALVE	1
	38	CY-129004-03010	PLATE, BAFFLE	1
	39	CY-129150-03070	BAFFLE, BREATHER	1
	40	CY-119802-03110	PLATE, DIAPHRAGM	1
	41	CY-119802-03121	COVER, DIAPHRAGM	1
	42	CY-119802-03130	DIAPHRAGM	1
	43	CY-119802-03141	SPRING, DIAPHRAGM	1
	45	CY-129004-11310	GASKET, VALVE COVER	1
	46	CY-22857-500100	SCREW 5X10,TAPPING	4
	47	CY-22857-500100	SCREW 5X10,TAPPING	4
	48	CY-124160-11360	KNOB	3
	49	CY-24311-000120	O-RING 1A P 12.0	3
	50	CY-129900-07900	LIFTER, ENGINE	1
	51	CY-26106-080162	BOLT M 8X 16 PLATED	2
	52	CY-119803-77830	HARNESS, GLOW PLUG	1
	53	CY-129008-77800	PLUG, GLOW	3
	54	CY-129008-77820	CONNECTOR, GLOW PLUG	1
