11.1 Thermal Impedance

Table 11-1. Thermal Impedance for the Package

Package

Typical θJA [15]

56 QFN[16]

12.93 oC/W

68 QFN[16]

13.05 oC/W

100 VFBGA

65 oC/W

100 TQFP

51 oC/W

11.2 Solder Reflow Peak Temperature

Following is the minimum solder reflow peak temperature to achieve good solderability.

Table 11-2. Solder Reflow Peak Temperature

Package

Minimum Peak Temperature[17]

Maximum Peak Temperature

56 QFN

240oC

260oC

68 QFN

240oC

260oC

100 VFBGA

240oC

260oC

Notes

15.TJ = TA + POWER x θJA

16.To achieve the thermal impedance specified for the QFN package, the center thermal pad should be soldered to the PCB ground plane.

17.Higher temperatures may be required based on the solder melting point. Typical temperatures for solder are 220 ± 5oC with Sn-Pb or 245 ± 5oC with Sn-Ag-Cu paste. Refer to the solder manufacturer specifications
