Dell 2230d - page 95

Setting the printer up in a new location

When the printer is set up, allow c learance around it as shown.

1300 mm (12.0 in.)

2300 mm (12.0 in.)

3200 mm (8.0 in.)

412.7 mm (0.5 in.)

5300 mm (12.0 in.)

Shipping the printer

When shipping the printer, use the ori ginal packaging or call the place of purchase for a relocation kit.
