Care and cleaning

27

Removing and refitting the side racks and catalytic panels

Note: only some models have catalytic panels and a lamp in the left oven wall.

Fig.20a Side rack and catalytic panel in full oven cavity Fig.20b Side rack in compact oven cavity

When refitting the side racks, make sure they are the right way up, as in the illustrations. When refitting the catalytic panels, make sure that:

the arrows are pointing upwards

the panel with the hole is on the left oven wall (if there is a lamp in the wall).

Note: in some models, the back of the oven is also a catalytic panel, but this is not reversible and should not be removed.

Drop-down grill element (some models)

Once you have removed the side racks, the grill element in some full ovens drops down (Fig. 21) The grill element itself is self-cleaning. Note: some grill elements are fixed.

Fig.21 Drop-down grill element
