Montering af emhætte



Vr

• Inden man hænger emhætten op, skal man stramme de to





skruer Vr, som sidder i hættens ophængningspunkter.





• Hæng emhætten op på de forberedte skruer 12a.





• Stram ophængningsskruerne 12a helt til.





• Ved at dreje på skruerne Vr nivelleres emhætten.

12a







Tilslutninger





VERSION FORBUNDET TIL AFTRÆKSKANAL





Når aftrækskanal-versionen opsættes, forbindes emhætteenheden

ø 150

ø 120

til kanalen med en flexslange eller et hårdt rør, Ø150 eller 120 10



9

mm – valget er op til den, der opsætter emhætten.



10

Tilslutning af rør på ø 150

• Indsæt studsen på ø 150 10 på emhættens udsugningshul.

Spænd røret fast med specielle rørklemmer. Disse medleveres ikke.

Tilslutning af rør på ø 120

Ved tilslutning af rør på ø120 mm, indsættes reduktionsstudsen 9 på studsen ø 150, som er monteret tidligere.

Spænd røret fast med specielle rørklemmer. Disse medleveres ikke.

I begge tilfælde skal man fjerne eventuelle lugtabsorberende kulfiltre.

14.1



LUFTUDSTRØMNING PÅ FILTRERENDE VERSION



• Før overgangsstykket 15 ind i støttebeslaget 7.3.



Før overgangsstykkets forlængere 14.1 ind på siden af over-

15



gangsstykket 15.



• Sørg for at udgangen på overgangsstykkets forlængere 14.1

ø 150



befinder sig ud for aftrækkets mundinger, både vandret og lod-



ret.



Forbind overgangsstykket 15 til emhættens hoveddels udgang





ved hjælp af et rør eller en flexslange med ø150, som det på-





hviler installatøren at vælge.



• Sørg for, at lugtfiltret med aktivt kul er monteret.

DK



2



20
