BASIC RECORDING & ONE-TOUCH TIMER RECORDING

Follow the steps to record TV programs.

Press [DVD] first.

1 Insert a recordable disc (refer to page

26 on how to insert a disc).

* Make sure the disc is compatible with this unit. (Refer to page 39 for the list of compatible discs.)

It may take a while to load

the disc.

• When inserting a brand-new DVD+RW/DVD-RW, the unit automatically starts to format.

• If titles have been recorded on the disc, the title list is displayed. Press [STOP C] to exit the title list.

2 Press [REC MODE] repeatedly to

select a recording mode.

Refer to “Recording Mode” on page 39.

SP(2Hr) 0h58m

3 Select the appropriate external input channel by pressing [SOURCE] or [CHANNEL / ].

Press [DTV/TV] to select analog TV or digital TV, then use [CHANNEL / ] or [the Number buttons] and [ • ] (for digital TV channels) to select a desired channel to record.

Refer to “Switching Analog Mode/Digital Mode” and “Channel Selection“ on page 33.

CH 12

EN 41

Introduction Connections Basic Setup Recording Playback Editing Function Setup VCR Functions Others
