МУФТА “A”







ВОДОПРОВОДНЫЙ КРАН



ВЫПУСК ВОДЫ

Водовыпускное

90 градусов

отверстие







очистителя





ВНИМАНИЕ

ОЧИЩАЕМАЯ ВОДА

Устанавливайте зажимной

фиксатор после установки













трубки

ВОДОВПУСКНОЕ

СОЕДИНИТЕЛЬНАЯ

Зажимной фиксатор

ОТВЕРСТИЕ

МУФТА



ОЧИСТИТЕЛЯ

Инструкции по замене

1.Отключите подачу воды.

2.Отметьте направление потока на фильтре.

3.Вставьте трубку подачи воды в водовпускное отверстие фильтра до упора.



НАПРАВЛЕНИЕ ПОТОКА

ВПУСКНОЕ

ВЫХОД



ОТВЕРСТИЕ



ДЛЯ ПОДАЧИ ВОДЫ



Примечание: Срез должен быть круглым, в противном случае возможна протечка воды.

4.После этого надежно зафиксируйте зажим. Зажим фиксирует трубку.

5.Включите воду и проверьте, нет ли протекания. Если вода протекает, повторите пункты 1, 2, 3, 4. Если протечка не устраняется, прекратите использование прибора и обратитесь к вашему дилеру.

6.Перед использованием пропустите воду через фильтр в течение 5 минут.

20_ yстановка

Удалите осадок из фильтра для воды (модель с фильтром).

-Откройте главный вентиль в квартире, чтобы проверить, подается ли вода через трубку для подачи воды на вход фильтра.

-Если вода не выходит из фильтра, проверьте, открыт ли водопроводный кран.

-Оставьте кран открытым, пока из фильтра не пойдет чистая вода и не будут удалены загрязнения и осадок, которые могли остаться в фильтре в процессе его изготовления.

ВЫХОД ФИЛЬТРА



ДЛЯ ВОДЫ

ФИЛЬТР



ТРУБКА ДЛЯ

ВОДА

ПОДАЧИ ВОДЫ



Крепление зажимного фиксатора очистителя.

-Установите зажимной фиксатор очистителя в необходимое место (например, под раковину) и надежно закрепите его винтами.

ЗАЖИМНОЙ ФИКСАТОР ОЧИСТИТЕЛЯ

Закрепите фильтр для воды.

-Закрепите фильтр-картридж, как это показано на рисунке справа.

ТРУБКА ДЛЯ ВОДЫ

ЗАЖИМНОЙ ФИКСАТОР ОЧИСТИТЕЛЯ

ОЧИСТИТЕЛЬ

DA99-02318Q-14.indb 20

15. 5. 12. ￿￿ 9:08

Page 20
