OUTLINE

FUNCTION

CODE

OUTLINE

FUNCTION

CODE

OUTLINE

FUNCTION

CODE

OUTLINE

Sets the magnification rate in character height

Prints the subsequent data with a character height magnified by a rate specified by the value of n.

n = 0 and "0"' Reset magnification

n = 1 and "1": Double magnification

Note:

You can print in quadruple magnification by combining horizontal and vertical double magnification commands.

You cannot combine with the inverted printed command.

Line feeds of lines including vertical expansion characters are doubled.

When font configuration is 6 X 12 dots of IBM block graphics characters, only the line amount is doubled.

The bottom of the characters are aligned when one line contains both vertical expanded characters and regular character sizes.

Selects underlining

<ESC> "-" "1" or <ESC> "-" <1>

(1B)H (2D)H (31)H or (1B)H (2D)H (01)H

Data following this code is printed out underlined. (However, the

spaces generated by horizontal tab are not underlined.)

Cancels underlining (Default)

<ESC> "-" "0" or <ESC> "-" <0>

(1B)H (2D)H (30)H or (1B)H (2D)H (00)H

Cancels underlined mode.

Selects upperlining

<ESC> "_" "1" or <ESC> "_" <1>

(1B)H (5F)H (31)H or (1B)H (5F)H (01)H

Data following this code is printed out with an upperline.

(However the spaces generated by horizontal tab are not upperlined.)

13
