Error responses

When the IPL T CR48 receives a valid command, it executes the command and sends a response to the host device. If the unit is unable to execute the command because the command contains invalid parameters, it returns an error response to the host.

E10 — Invalid command

E12 — Invalid port number

E13 — Invalid parameter

E14 — Not valid for this configuration

E17 — System timed out

E22 — Busy

E24 — Privilege violation

E25 — Device not present

E26 — Maximum number of connections exceeded

E27 — Invalid event number

E28 — Bad filename/file not found

E31 — Attempt to break port pass-through when not set (A user or software attempted to disable the port redirect feature when it wasn’t already set or active.)

References to errors (at command descriptions on the following pages)

24= Commands that give E24 (privilege violation) if not administrator level

27= Commands that may give E27 (invalid event number)

28= Commands that may give E28 (file not found)

URL Encoding

URL encoding is the method of using ASCII hexadecimal characters to display specific characters in a URL. URL encoding is used for several reasons. On some operating systems, certain characters are unsafe or not available, and others are reserved by the HTML or URL specification. URL encoding is used to ensure compatibility and functionality with most Internet browsers. As a general rule, use the URL hexadecimal encoding method shown in the following tables when these characters appear in your URLs.

The following types of characters do not require encoding in a URL.

Alphanumerics Special characters Reserved characters

0-9 a-z A-Z $ _ _ . + ! * ( ) , ; / ? : @ = &

When used for their reserved purposes, these characters do not require encoding within a URL.

IPL T CR48 • Communication and Control

26

Page 31 Page 33
Image 32
