Specifications, Part Numbers, Accessories, cont’d

These items are included in each order of the CVEQ 100 MAAP or SVEQ 100 MAAP.

Included parts

Replacement



part number

CVEQ 100 MAAP (black) or

70-667-02

SVEQ 100 MAAP (black) or

70-668-02

CVEQ 100 MAAP (white) or

70-667-03

SVEQ 100 MAAP (white) or

70-668-03

CVEQ 100 MAAP (RAL9010) or

70-667-05

SVEQ 100 MAAP (RAL9010)

70-668-05

User's manual



12 VDC, 2 A external power supply

70-055-01

IEC power cord







These items are included in each order of the CVEQ 100 D or SVEQ 100 D.

Included parts

Replacement



part number





CVEQ 100 D composite

60-867-01

video audio line driver



or



SVEQ 100 D S-video audio

60-868-01

line driver



Faceplate, black



Faceplate, white



Decora® wall plate, black



Decora® wall plate, white



12 VDC, 2 A external power

70-055-01

supply



IEC power cord



Tweeker (small screwdriver)



User’s manual







Optional Accessories

These items are optional mounting accessories for the CVEQ 100 or SVEQ 100.

Description

Part number

RSF 123 VersaTools® rack shelf kit

60-190-20

RSB 123 VersaTools rack shelf

60-604-21

RSU 126 6" deep universal rack shelf kit

60-190-10

RSB 126 6" deep basic rack shelf

60-604-11

RSU 129 1U universal rack shelf kit

60-190-03

RSB 129 1U basic rack shelf

60-604-01

MBU 123 under-desk mount kit

70-212-01

MBU 125 under-desk mount kit

70-077-01

MBD 125 through-desk mount kit

70-077-02

MBB 100 back of the rack mount kit

70-367-01

These items are optional cables and adapters for the CVEQ 100 or SVEQ 100.

Description

Part number

MHR-2P Plenum S-video cable

22-129-0X

MHR-2 Non-Plenum S-video cable

22-123-0X

SVHSF-BNCM adapter (S-video female to

26-541-0X

2 male BNCs)



RCAF-BNCM/10 adapter (RCA female to

100-229-01

BNC male, Qty. 10)



AV RCA/6 cable (RCA male to male 6')

IN8906

A-8

CVEQ 100 and SVEQ 100 Series • Specifications and Parts

CVEQ 100 and SVEQ 100 Series • Specifications and Parts

A-9
