Setting the color temperature

Use this procedure to set color tone produced by the plasma display.

Example: Setting “1”

Press the PROCEED button on the remote control to

display the MAIN MENU on the screen, then...

1.Use the and buttons to select “PICTURE”, then press the PROCEED button.

The “PICTURE” screen appears.

2.Use the and buttons to select “COLOR TEMP.”.

P I C T U R E

CONTRAST

































BRIGHTNESS

















































SHARPNESS

















































COLOR

































TINT





R









G

























PICTURE MODE

:

MEMORY



:

2









COLOR TEMP.











NR





: OFF

SEL.

ADJ.







RETURN





EXIT

3. Use the  and  buttons to select “1”.

The mode switches as follows when the  and  buttons are pressed:

2 3 PRO 1

* See page 23 to set “PRO”.

4.Once the setting is completed...

Press the EXIT button to return to the main menu.

To delete the main menu, press the EXIT button once more.

Information

Setting the color temperature

1

High (bluer)

2

Middle (Standard)

3

Low (redder)

Restoring the factory default settings

Select “RESET” under the function menu. Note that this also restores other settings to the factory defaults.

COLOR TEMP. : 1

*If neither the  or  button is pressed within 5 seconds, the current selection is set and the previous screen reappears.
