Marantz PD5020D manual Setting a computer image to the correct RGB select screen, RGB Select modes

Page 44

Setting a computer image to the correct RGB select screen

With the computer image, select the RGB Select mode for a moving image such as (video) mode, wide mode or digital broadcast.

Example: Setting the “RGB SELECT” mode to “MOTION ”

Press the PROCEED button on the remote control to

display the MAIN MENU on the screen, then...

1.Use the ▲ and ▼ buttons to select “OPTIONS”, then press the PROCEED button.

The “OPTIONS” screen appears.

2.Use the ▲ and ▼ buttons to select “RGB SELECT”.

O P T I O N S

AUDIO INPUT









AUDIO1



: VIDEO1

AUDIO2



: HD/DVD1

AUDIO3



: RGB1

BNC SELECT



: RGB

RGB SELECT



: AUTO



HD SELECT



: 1080B

PICTURE SIZE

: ON

SEL.

ADJ.





RETURN



EXIT

3.To set the RGB select mode to “MOTION” ...

Use the ◀ and ▶ buttons to select “MOTION”.

The mode switches as follows each time the ◀ or ▶ button is pressed:



→

AUTO ↔ STILL ↔

MOTION ↔

WIDE1 ↔ WIDE2 ↔ DTV ←























































O P T I O N S









AUDIO INPUT



















AUDIO1

: VIDEO1











AUDIO2

: HD/DVD1











AUDIO3

: RGB1











BNC SELECT

: RGB











RGB SELECT



: MOTION











HD SELECT

:

1080B











PICTURE SIZE

: ON











SEL.



ADJ.







RETURN













EXIT



4.Once the setting is completed ...

Press the EXIT button to return to the main menu.

To delete the main menu, press the EXIT button once more.

Information

⬛RGB SELECT modes

One of these 6 modes must be selected in order to display the following signals correctly.

AUTO .............. Select the suitable mode for the

specifications of input signals as listed in the table “Computer input signals supported by this system” on page 55.

STILL .............. To display VESA standard signals.

(Use this mode for a still image from a computer.)

MOTION .......... The video signal (from a scan

converter) will be converted to RGB signals to make the picture more easily viewable. (Use this mode for a motion image from a computer.)

WIDE1 ............. When an 852 dot× 480 line signal

with a horizontal frequency of 31.7kHz is input, the image may be compressed horizontally. To prevent this, set RGB SELECT to WIDE1.

WIDE2 ............. When an 848 dot× 480 line signal

with a horizontal frequency of 31.0 kHz is input, the image may be compressed horizontally. To prevent this, set RGB SELECT to WIDE2.

DTV ................. Set this mode when watching digital

broadcasting (480P).

See page 55 for the details of the above settings.

⬛Restoring the factory default settings

Select “RESET” under the function menu. Note that this also restores other settings to the factory defaults.

37

Page 43 Page 45
Image 44
