Daily Operations / Connections (cont.)

10

7Available signals The following signals are available for this monitor.

Video signals





Signal format







Input terminal





No.

Signal name

shown in the status display

VIDEO

COMPO.(Analog

E. AUDIO SDI (IN 1, IN 2)*2

DVI-D (HDCP)





(page 7)

component)*1

SD/HD (1.5G)

3G SDI



DUAL LINK

(Digital component/digital RGB)









1

NTSC

NTSC



2

PAL

PAL



3

B/W50

B/W50



4

B/W60

B/W60



5

480/60i

480/60i



6

480/59.94i

480/59.94i



7

576/50i

576/50i



8

480/60p

480/60p



9

480/59.94p

480/59.94p



10

576/50p

576/50p



11

640*480/60p

640*480/60p



12

640*480/59.94p

640*480/59.94p



13

720/60p

720/60p



14

720/59.94p

720/59.94p



15

720/50p

720/50p



16

720/30p

720/30p



17

720/29.97p

720/29.97p



18

720/25p

720/25p



19

720/24p

720/24p



20

720/23.98p

720/23.98p



21

1080/60i

1080/60i



22

1080/59.94i

1080/59.94i



23

1035/60i

1035/60i

*3



*3

24

1035/59.94i

1035/59.94i

*4



*4

25

1080/50i

1080/50i



26

1080/60p

1080/60p



27

1080/59.94p

1080/59.94p



28

1080/50p

1080/50p



29

1080/30p

1080/30p



30

1080/29.97p

1080/29.97p



31

1080/25p

1080/25p



32

1080/24p

1080/24p



33

1080/23.98p

1080/23.98p



34

1080/30psF

1080/30psf

*3

*3



35

1080/29.97psF

1080/29.97psf

*4

*4



36

1080/24psF

1080/24psf



37

1080/23.98psF

1080/23.98psf



38

1080/25psF

1080/25psf



: Acceptable

—: Not acceptable

*1 Analog component signals are compatible with Y on sync signals.

*2 Compatible with EMBEDDED AUDIO signals. *3 The signal is recognized as 1080/60i, and the

status is displayed as “1080/60i.”

*4 The signal is recognized as 1080/59.94i, and the status is displayed as “1080/59.94i.”

On the signal format

The following messages appear depending on the type of input signals and their conditions.

When a DVI-D signal protected with HDCP is input

\*” (at the end of the indication)

When no video signal comes in

\“NO SYNC”

When a noncompliant video signal comes in

\“Out of range”

When “COLOR SYSTEM” (“FUNCTION

SETTING” on page 16) is set to “AUTO” and the noncompliant composite video signals come in

\“OTHERS”
