2 • 6 Feeding one card at a time

A Manual Feed Slot is avalable on the side of the Card Feeder cover for feeding single cards. Cleaning Cards are fed manually through this slot.

The Feeder must be empty for manual card feeding to work properly.

For one-at-a-time printing, feed cards through slot on side of Feeder.

Do not feed more than one card at a time.

14 OPERATION
