PN9108U User Manual

System Information:

The System Information section allows you to provide a name and description for the PN9108U installation. Providing a name and description is optional, but makes it convenient for system operators to distinguish among installation groups in large, installations when there are several groups of daisy chained PN9108Us.

The name can be up to 30 characters.

Note: This name is not the same as the Station Name which is set in the Configuration dialog box (see p. 27).

Administrator:

This section sets the administrator’s login name and password.

MThe default administrator name is: administrator

MThe default password is: password

For security purposes, we strongly recommend that you change the default values to something unique. The minimum number of alphanumeric characters for both is 4; the maximum number is 15.

Connection Control:

MSession Timeout sets a timeout value. If there is no input from the logged in operator for the amount of time set with this function, the operator is automatically logged out and the session is terminated. Valid settings are from 2 ~ 99 minutes. The default is 3 minutes. A setting of 0 (zero) disables this function.

MIf No timeout on monitoring is enabled, the system will not time out when you are using the Monitor function to view the power status of your installation (see p. 34 for Monitor details).

22

2005-09-07
