ATEN Technology PN9108U user manual

Page 45

Chapter 4 - Administration

MIt is also possible to attach an individual UPS for each computer to the PN9108U’s outlet ports. In this case:

MDo not enable the PN9108U’s UPS function - since that function only works with a UPS device attached to its RS-232 port.

MConfigure the UPS devices according to the documentation provided with each of them.

MSet the power outlet configuration for each of the affected ports to Kill the Power.

UPS

UPS

PN9108U

31

2005-09-07
