4-2CHAPTER 4: TROUBLESHOOTING

Troubleshooting

When a problem occurs during the test phase, the Status LEDs light in

During the Test

a particular pattern. Table 4-1 shows the Status LED pattern, the

Phase





problem associated with that pattern, and the action to take.

Table 4-1System Self-test Errors













Status LEDs









1

2

3

4

Test LED

Power/Fault LED

Meaning and Action















Off

Off

On

On

On

Yellow

EEPROM checksum test failed.













Contact your network supplier.















Troubleshooting

When a problem occurs during the load phase, the Status LEDs light in

During the Load

particular patterns. Table 4-2 shows the Status LED patterns, the

Phase





problems associated with these patterns, and the actions to take.

Table 4-2System Software Load Errors













Status LEDs









1

2

3

4

Load LED

Power/Fault LED

Meaning and Action















Off

Off

On

On

On

Yellow

Software image file has been deleted or boot source and













image file names do not match.













Reload the system software. Refer to the software













guide.















On

Off

Off

Off

On

Yellow

Unable to transmit BOOTP request. Bridge/router is not













connected to token ring correctly.













Check cable connections.















On

Off

Off

On

On

Yellow

No response to BOOTP request. BOOTP server not present













or incorrectly configured.













Check TFTP server configuration and verify the MAC













address of the bridge/router. Press Reset to retry the













system software load. If the load is unsuccessful, call













your network supplier for assistance.















On

Off

On

Off

On

Yellow

No response to Address Resolution Protocol (ARP) request













from TFTP server. TFTP server not present or incorrectly













configured.

Check TFTP server configuration and verify the MAC address of the bridge/router. Press Reset to retry the system software load If the load is unsuccessful, call your network supplier for assistance.

(continued)
