Installation

Ensure that the following accessories are included with your plasma display. If an accessory is missing, please contact the dealer where you purchased the product.

	1.5V
Owner’s Manual	Batteries	Power Cord
		Power Cord

Remote Control	D-sub 15 pin cable	DVI computer cable

Soft cloth

(MW-71PY10G only )

Option Extras

-Optional extras can be changed or modified for quality improvement without any notification new optional extras can be added.

-Contract your dealer for buying these items.

Tilt wall mounting bracket

Desktop stand

Video cables

Audio cables

10 Plasma Monitor
