Page 17

Installation

HDMI

-HDMITM, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC."

-This monitor can receive the High-Definition Multimedia Interface(HDMI).

-This monitor supports HDCP(High-bandwidth Digital Contents Protection) Protocol for 480p, 720p, 1080i modes.

-When you Connect with HDMI Source Devices (DVD Player or Set Top Box) supporting Auto HDMI function, automatically, support Plug & Play and then set the HDMI Source Devices(1920 x 1080i). After reading in HDMI Source Devices using Display Data Channel(DDC) Protocol, EDID stored in monitor is used. If HDMI Source Devices not supported Auto HDMI is been, the Resolution is setted, manually.

-To get the best picture quality, adjust the DVD Player or Set Top Box output resolution to 1920 x 1080i.

How to connect

When Source Devices(DVD Player or Set Top Box) support HDMI.

-If Source Devices have HDMI Output Connector, Source Devices connect to DTV with HDMI Cable .(not supplied with the product).

-If Source Devices support Auto HDMI, automatically, Source Devices divert output resolution in 1920 x 1080i. But if not, resolution divert Manually Setting for reference Manual of Source Devices.

-To get the best picture quality, adjust the DVD Player or Set Top Box output resolution to 1920 x 1080i.

-Because HDMI sends Digital Video and Audio with one cable, need not especial Audio Cable for using HDMI Cable.

Reference

Cable sample

HDMI Cable (not supplied with the product)

Owner’s Manual 17
