Elinchrom BX 500RI EL- Skyport Transceiver For Wireless Triggering Setup, EL-Skyport on / off

EL- Skyport Transceiver For Wireless Triggering – Setup English

The EL-Skyport on / off, Group, Frequency Channel and the Power Steps Per Push can be customised.

EL-Skyport on / off

Press the flash power up-down buttons together to enter into the “Advanced Feature Setup”

Display shows	Change settings with the flash power up-down buttons
r.0	EL-Skyport off
r.1	EL- Skyport on
r.2	EL-Skyport speed mode (only available with EL-Skyport Speed)

After 3 to 4 seconds the settings are saved automatically and the display shows the flash power setting.

Group Settings

Press the flash power up-down buttons together to enter into the “Advanced Feature Setup”. Then, scroll to G.1 using the Prop/Free button.

Display shows	Select Group with the flash power up-down buttons
G.1	Group 1 (standard setting)
G.2	Group 2
G.3	Group 3
G.4	Group 4

After 3 to 4 seconds the settings are saved automatically and the display shows the flash power setting.

Frequency Channel Settings

Press the flash power up-down buttons together to enter into the “Advanced Feature Setup”. Then, scroll to F.1 using the Prop/Free button (only use in cases of interference with other systems).

Display shows	Change the Channel with the flash power up-down buttons
F.1 to F.8	Select Frequency Channel from 1 – 8.
	Note: The transmitter must have the same Frequency Channel
	setting. Standard setting is Frequency Channel 1.

After 3 to 4 seconds the settings are saved automatically and the display shows the flash power setting.

Power Steps Per Push

Press the flash power up-down buttons together to enter into the “Advanced Feature Setup” Then, scroll to i.1 using the Prop/Free button.

Display shows	Select values with the flash power up-down buttons
i.0	+/- 1f-stop
i.1	+/-	1/10 (standard setting)
i.2	+/-	2/10
i.3	+/-	3/10
i.4	+/-	4/10
i.5	+/-	5/10

After 3 to 4 seconds the settings are saved automatically and the display shows the flash power setting.

13
