overview

Features

With the state-of-the-art digital signal processing technology, full digital image processing and special algorithm of 600-line high resolution implemented

High performance surveillance camera, equipped with x34 zoom lens and digital zoom IC, enabling monitoring up to 544 times

WDR to cover the full screen irregardless of its brightness

DAY/NIGHT to improve the sensitivity by automatic conversion into the black and white mode at night or in the environment with low illumination

White Balance to control the brightness to the illumination

Backlight Compensation under spotlight or utmost bright illumination

Auto Focus to automatically adjust the focus to the subject movement

Privacy zone to hide a specific area for personal privacy

PAN/TILT for precise control at high speed

What’s Included

Please check if your camera and accessories are all included in the product package.

Camera

User Manual

Housing

Connectors

User Manual

Grease

Pin & Bush
