Alpine KCA-420i Displaying the Text, Touch P1/3 on the function guide to change to P2/3

Page 13

Controling from the CVA-1004 model

1 Press FUNC.

The FUNC indicator lights.

2 Press 5 (

) within 5 seconds.

The songs will be played back repeatedly.

REPEAT → (off) → REPEAT

(Repeat One) (Repeat One)

3 To cancel repeat play, select (off) with the above procedure.

Controling from the IVA-D901 model

1 Press 4 (REPEAT) to play back repeatedly the song being played.

The song will be played repeatedly.

REPEAT → (off) → REPEAT

(Repeat One) (Repeat One)

2 Press 4 (REPEAT) again and select (off) to deactivate the repeat play.

Controling from the IVA-D300 model

1 Touch [P1/3] on the function guide to change to [P2/3].

The function guide changes.

2

Touch [

] and select the desired Repeat



play.





The song will be played repeatedly.



RPT → (off) → RPT

3

Touch [

] again and select (off) to

deactivate Repeat play.

Displaying the Text

You can display the playlist name, or the tag information of a song in the iPod.

The type of characters (number/letter, etc.) and the display order differs depending on the head unit. Refer to “Displaying the Title/ Text” of the head unit’s Owner’s Manual.

The iPod data is displayed in the same way as MP3 data, with some minor differences.

Head Unit and iPod display indications (only the differences are displayed)

Head Unit

iPod

Folder No.

File No.*

File No.

(1) Fixed display

Folder Name

“----” fixed display

File Name

“iPod” fixed display

Frame

Not displayed**

* The maximum file number that can be displayed is 255. Any file beyond 255 is still displayed as 255.

** Though the numeric value displayed differs from the actual sampling or bit rate (depending on head unit), this is not a malfunction.

Only alphanumeric characters (ASCII) can be displayed.

When the artist name, album name, or song name is set on iTunes, and the amount of characters is increased, songs may not be played back when connected to the unit. Therefore, a maximum of 250 characters is recommended. The maximum number of characters for the head unit is 64 (64 byte).

After setting the ignition to ACC, ON or OFF, or recon- necting the iPod to the adapter, when the first song is played back, the artist name, album name or song name may not be correctly displayed.

Some characters may not be correctly displayed.

“NO SUPPORT” or “NO SUPRT” is displayed when text information is not compatible with the adapter. (The display differs depending on the head unit.)

Controling from the CDA-9835/CDA-9833/ CDA-9831/CDA-9830/CDA-9827/CDA-9826/CDA- 9825/CDA-9820XM/CVA-1004 models

1 Press TITLE ( ) or DISP/TITLE ( ).

The playlist name or the tag information is displayed.

12-EN

Image 13
