Stepwise startup

Step 3: Connecting the base station

Plug-in power supply socket

power cord				phone cord
power cord				phone cord

cord channel for

power and phone cords

power cord RJ-11 plug

power cord RJ-11 plug

Underside of base station case

Phone cord

Insert the RJ-11 plug on your phone cord into the base sta- tion. The jack on the bottom of the base station is marked with the following symbol:

Insert the phone plug on your phone cord into your phone socket.

Power cord

Insert the RJ-11 plug on your power cord into the base station. The jack on the bottom of the base station is mar- ked with the following symbol:

Insert the power cord plug-power supply into a socket.

For safety reasons, the phone must only be ope- rated with the supplied Siemens adapter.
