Panasonic KX-TG5428 Battery installation, If you subscribe to an xDSL service

Page 10

Preparation

If you subscribe to an xDSL service

LPlease attach a noise filter (contact your xDSL provider) to the telephone line between the base unit and the telephone line jack in the event of the following:

–Noise is heard during conversations.

–Caller ID features (page 24) do not function properly.

To single-line telephone jack (RJ11C)

Telephone

line cord Noise filter (For xDSL users)

Battery installation

1 Release the battery cover latch and slide the cover open.

2 Insert the battery (1), and press it down until it snaps into the compartment (2).

2 1

3 Close the handset cover.

4 Fasten the battery cover latch.

10For assistance, please call 1-800-211-PANA (7262).
