WZT1500 I.S. 325-1394 10/28/03 3:41 PM Page 3

To reduce the risk of FIRE, ELECTRIC SHOCK, EXPOSURE TO EXCES- SIVE UV RADIATION, OR INJURY TO PERSON, please follow the fol- lowing instructions.

•WARNING: Risk of burn. Disconnect power and allow fixture to cool before changing bulb or handling fixture.

•Bulb gets HOT quickly! Only contact switch/plug when turning on.

•Do not touch hot lens, guard, or enclosure.

•Do not remain in light if skin feels warm.

•Do not look directly at lighted bulb

•WARNING: Risk of fire. Keep away from flammable vapors and materials

•Use only a recommended, or lower wattage halogen type "T" bulb. Use of any other bulb will damage the fixture and void the warranty. Installing higher wattage bulbs could create a fire hazard.

•Do not touch the bulb at any time. Use a soft cloth or gloves. Oil from skin may damage bulb.

•WARNING: Risk of Personal Injury. Exposure to Ultraviolet (UV) Radiation. Do not operate with a damaged or missing protective barrier.

•Do not direct light at persons

•Fixture must be connected to a 120 Volt, 60 Hz power source. Any other connection voids that warranty.

•The electrical system, and the method of electrically connecting the fixture to it, must be in accordance with the National Electric Code and local building codes.

•WARNING: Risk of Electric Shock. Do not use with extension cord near water or where water may accumulate. Keep lamp at least 16 feet from pools and spas. Keep plugs and receptacles dry. For use only on GFCI protected circuits.

•Disassembly of the fixture will void the warranty.

•If lens is replaced, use only tempered safety glass of equal thickness.

•For maximum bulb life, position light so that the halogen bulb remains within 4° of horizontal.

•For indoor and outdoor use.

•UL / cUL LISTED for wet locations

•WARNING: Deviation from these instructions may result in a risk of fire, burns or electric shock.

SAVE THESE INSTRUCTIONS

Assembling your fixture:

Step 1: Remove fixtures, pole, and leg assembly from box. Slide pole into top bracket of leg assembly until it rests in the bottom bracket. Tighten locking bolt in lower bracket with wrench to secure pole.

Step 2: Pull legs out, extending to full open position so that the top black bracket slides down until it lines up with red line on label then tighten knob to lock in place (Figure A).

3
