Cooper Lighting WZT1500 Bonus bulb included, Replacing the bulb, Aiming the fixture

Page 5
Fig. E
Fig. F

WZT1500 I.S. 325-1394 10/28/03 3:42 PM Page 5

NOTE: Legs should be secured with sand bags or other suitable weight:

When used on uneven or rocky surfaces

When used in windy areas

Anytime extra stability is required.

Bonus bulb included:

This fixture includes spare bulbs, which insure that you

Fig. C

can always finish your job or project without interruption

SPARE BULB

due to bulb failure. The spare bulbs and holder are locat-



ed in the back of handle of the light fixture (Figure C).

Replacing the bulb:

NOTE: Always handle halogen bulbs with gloves or with a clean soft cloth.

Oil from your skin can cause premature failure of the bulb.

Step 1: Make sure fixture is turned OFF and unplugged.

Fig. D

Step 2: Loosen the plastic knob on the back on the fixture

SPARE BULB

door (figure D).



Step 3: The door frame and lens assembly will swing



down allowing access to the bulb.



NOTE: Each fixture contains one 500-watt and one 250- watt bulb. The smaller socket accepts a 250-watt max bulb and the larger socket accepts a 500-watt max bulb.

Step 4: Using gloves or soft cloth, press the old bulb to one side of the spring loaded socket as indicated on the metal reflector. Remove opposite end of bulb from the other side of

the socket. Remove the new bulb from its package making sure not to touch bulb with

bare hands. Reverse this procedure to install

a new replacement bulb (figure E).

Step 5: Replace the door frame and lens assembly and secure it using the plastic knob.

Aiming the fixture:

Make sure the light fixture is in the OFF position and cool. Loosen the knobs located on the side of the light fixture housing. Using the top carrying handle tilt to desired position then retighten knobs (figure F). There is a stop that restricts the downward movement of the fixture for your safety. To prevent overheating and risk of burns or fire, do not aim the fixture down at an angle of more than 10 degrees from horizontal.

Two Year Limited Warranty:

Cooper Lighting (“the Company”) warrants this product (“the product”) against defects in material or workmanship for a period of two years from

5

ENGLISH
