Maintenance & Service Guide

Presario 1900 Series

Models: 1900T, 1905, 1906, 1910, 1915, 1919, 1920,

1922, 1925, 1926, 1927, 1928, 1929, and 1930











Before You Begin



Specifications



Parts Catalog





















Removal Sequence



Troubleshooting



Battery Operations





















Product Description



Pin Assignments



Index











Specifications

System I/O Address

I/O Address



System Function (Shipping Configuration)







0000 - 000F



Direct Memory Access Controller

0020

- 0021



Programmable Interrupt Controller

0040

- 0043



System Timer

0060

- 0060



Standard 101/102-Key or Microsoft Natural Keyboard

0061

- 0061



System Speaker

0064

- 0064



Standard 101/102-Key or Microsoft Natural Keyboard

0070

- 0071



System CMOS/Real Time Clock

0081 - 008F



Direct Memory Access Controller

00A0 - 00A1



Programmable Interrupt Controller

00C0 - 00DF



Direct Memory Access Controller

00E0

- 00E1



Motherboard Resources

00F0 - 00FF



Numeric Data Processor

0170

- 0177



Intel 82371AB/EB PCI Bus Master IDE Controller

01F0 - 01F7



Intel 82371AB/EB PCI Bus Master IDE Controller

0201

- 0201



Gameport Joystick

0274

- 0277



IO Read Data Port for ISA Plug and Play Enumerator

0376

- 0376



Intel 82371AB/EB PCI Bus Master IDE Controller

0378 - 037F



Printer Port (LPT1)

03B0 - 03BB



NeoMagic NMG5 Graphics Controller

03C0 - 03DF



NeoMagic NMG5 Graphics Controller

03F0 - 03F5



Standard Floppy Disk Controller

03F6 - 03F6



Intel 82371AB/EB PCI Bus Master IDE Controller

03F7 - 03F7



Standard Floppy Disk Controller

03F8 - 03FF



Communications Port (COM1)

03D0 - 04D1



Motherboard Resources

0CF8 - 0CFF



PCI Bus

1000 - 103F



Motherboard Resources

1040 - 104F



Motherboard Resources

1050 - 105F



Intel 82371AB/EB PCI Bus Master IDE Controller

1060 - 107F



Intel 82371AB/EB PCI to USB Universal Host Controller

1080

- 10FF



PCI Fast Ethernet DEC 21143 Based Adapter

1400

- 14FF



PCI Communication Device

1800

- 1807



PCI Communication Device

System Memory Catalog

Memory Address



Device







00000000 - 0009FFFF



System board extension for PnP BIOS

000A0000 - 000AFFFF



NeoMagic NMG5 Graphics Controller

000B0000 - 000BFFFF



NeoMagic NMG5 Graphics Controller

000C0000 - 000CBFFF



NeoMagic NMG5 Graphics Controller

000E4000 - 000FFFFF



System Board Extension for PnP BIOS

00100000 - 03FFFFFF



System Board Extension for PnP BIOS

04000000 - 04000FFF



Texas Instruments PCI-1225 CardBus Controller

04001000 - 04001FFF



Texas Instruments PCI-1225 CardBus Controller

F4000000

- F40000FF



PCI Communication Device

F4000400

- F40007FF



PCI Fast Ethernet DEC 21143 Based Adapter

F4100000

- F41FFFFF



NeoMagic NMG5 Graphics Controller

F4100000

- F47FFFFF



Intel 82443BX Pentium(r) II Processor to AGP







Controller

F4200000

- F42FFFFF



PCI Multimedia Audio Device

F4400000

- F47FFFFF



NeoMagic NMG5 Graphics Controller

F4C00000 - F4FFFFFF



PCI Multimedia Audio Device

F4C00000 - F5FFFFFF



Intel 82443BX Pentium(r) II Processor to AGP







Controller

F5000000

- F5FFFFFF



NeoMagic NMG5 Graphics Controller

F8000000

- FBFFFFFF



Intel 82443BX Pentium(r) II Processor to PCI







Bridge (with GART Support)

FFF80000 - FFFFFFFF



Motherboard Resources

Display Information

12.1 in TFT Display



U.S.

Metric

12.1 in TFT





Dimensions

1.1 in

234mm



Height

11.6 in

294.7mm

Depth

9.2 in

29mm

Width





13.3 in TFT





Dimensions







1.2 in

234mm

Height

294.7mm

11.6 in

Depth

30.5mm

9.2 in

Width







Diskette Drive

Storage Drives

Capacity per Diskette (High/Low)

Diskette Size

Number of LED Indicators (Read/Write)

Number of Drives Supported

Drive Rotation (rpm)

Transfer Rate (Kbps/Sec)

Bytes per Sector

Sectors per Track (High/Low) Access Times

Track-to-Track (ms)

Head Setting (ms)

3.5 in Drive

LS-120 Drive

Low

720KB

Information

High

1.44MB

Not Applicable

3.5 in

1

1

360

Low 31

High 62

512

Low 9

High 18

3ms

15ms

Cylinders (High/Low)

Not Available

Number of Read/Write Heads

2

Hard Drive

Hard Drives



Models



DBCA-

DBCA-

DCXA-





20648

206480

21000











Capacity Per Drive

4.8-GB

6.4-GB

10.0-GB



Drive Type



U-DMA/33

U-DMA/33

U-





DMA/33





















Logical Configuration















Cylinders



10068

13424



16383



Heads



3





4



6



Sectors per Track

63





63



63



Bytes per Sector

512





512



512



Seek Times

















(Typical, including settling Read



Read

13ms Read



in ms)



13ms



Write

14ms 12ms









Write







Write



Single Track



14ms



Read



14ms









Read



2.5ms







Full Stroke





Write



Read





2.5ms

3.0ms



2.5ms









Write



Read

23ms

Write









3.0ms

3.0ms









Read



Write















24ms



Read









23ms







23ms









Write







Write









24ms







24ms



Transfer Rate

16.6MB/s

16.6MB/s

16.6MB/s



At interface



































Hard Drives, continued







Models



MHH20

MHH20 64AT

MHG2





48AT

102AT



Capacity Per Drive

4.8-GB

6.4-GB

10.0-GB



Drive Type



U-DMA/33

U-DMA/33

U-





DMA/33





















Logical Configuration















Cylinders



Not



13424



16383



Heads



Available

4



6



Sectors per Track

Not



63



63



Bytes per Sector

Available

512



512









Not

















Available















Not

















Available









Seek Times

















(Typical, including settling Read

N/A

Read

13ms

Read



in ms)



Write

N/A Write

14ms 13ms



















Write



Single Track



Read

N/A

Read



N/A









Write

N/A 2.5ms







Full Stroke



Read

N/A

Write



Read





3.0ms



1.5ms









Write

N/A

Read

23ms

Write















N/A















Write



















24ms



Read



















23ms



















Write



















N/A



Transfer Rate

15.8MB/s

16.6MB/s

15.8MB/s



At interface



































Hard Drives, continued







Models



DK238 A-

DK228 A-65

DK239 A-









43





65



Capacity Per Drive

4.3 GB

6.4



6.4 GB



GB(12.7mm)



Drive Type













U-















DMA/33





















Logical Configuration















Cylinders



Not



13424



16383



Heads



Available

4



6



Sectors per Track

Not



63



63



Bytes per Sector

Available

512



512









Not

















Available















Not

















Available









Seek Times

















(Typical, including settling Read

N/A

Read



Read



in ms)



Write

N/A Write



Write



















N/A



Single Track



Read

N/A















Write

N/A





Read



Full Stroke



Read

N/A





Write









N/A









Write

N/A





Read





































Write



















N/A



Transfer Rate















At interface















CD ROM or DVD Drive







































CD ROM Drive



DVD Drive (4X)







(24X)























Models

CRN-

CDR-

DRD-424

SD-C2202







8142B

U242Z











Dimensions

















Width

128mm

Not

128mm

128mm



Height

12.7mm

Available 12.7mm

12.7mm



Depth

129mm

Not

129mm

129mm









Available

















Not

















Available











Weight

300g

Not

280g



270g











Available











Rotational

5000RPM

Not

2300 RPM

2300RPM



Speed



Available











Typical

16.67MB/s Not

16.6MB/s(PIO) 16.7MB/s(PIO)



Transfer

3600KB/s

Available 5400KB/s

5400KB/s



Rate



Not











Sustained



Available











Data

















Transfer

















Rate

















Access

110ms

Not

150ms

140ms



Time



Average



Available











Random

















Access

















Time

















Spin Up

5s

Not

<15s*1

3.8s





Time



Available











Data Buffer 1Mbit

Not

128KB



128KB



Capacity



Available
