HP 6005 Pro manual 6Solving Audio Problems, Sound cuts in and out Cause Solution

Page 30

Solving Audio Problems

If the computer has audio features and you encounter audio problems, see the common causes and solutions listed in the following table.

Table 2-6Solving Audio Problems

Sound cuts in and out.

Cause

Solution





Processor resources are being used by other open

Shut down all open processor-intensive applications.

applications.









Direct sound latency, common in many media player

In Windows XP only:

applications.

1.

From the Control Panel, select Sounds and Audio







Devices.



2.

On the Audio tab, select a device from the Sound





Playback list.



3.

Click the Advanced button and select the Performance





tab.



4.

Set the Hardware acceleration slider to None and the





Sample rate conversion quality slider to Good and





retest the audio.



5.

Set the Hardware acceleration slider to Full and the





Sample rate conversion quality slider to Best and





retest the audio.







Sound does not come out of the speaker or headphones.

Cause

Solution





Software volume control is turned down or muted.

Double-click the Speaker icon on the taskbar, then make sure that Mute is not selected and use the volume slider to adjust the volume.

Audio is hidden in Computer Setup.

Enable the audio in Computer Setup: Security >



Device Security > System Audio.





The external speakers are not turned on.

Turn on the external speakers.





The audio device may be connected to the wrong jack.

Ensure that the device is connected to the correct jack on the



computer. The speakers should be plugged into the rear line-



out jack and the headphones should be plugged into the front



headphone jack.





External speakers plugged into the wrong audio jack on a

See the sound card documentation for proper speaker

recently installed sound card.

connection.





Digital CD audio is not enabled.

Enable digital CD audio. In the Device Manager, right-click on



the CD/DVD device and select Properties. Make sure Enable



digital CD audio for this CD-ROM device is checked.





Headphones or devices connected to the line-out connector

Turn on and use headphones or external speakers, if

mute the internal speaker.

connected, or disconnect headphones or external speakers.





Computer is in standby mode.

Press the power button to resume from standby mode.





24 Chapter 2 Troubleshooting Without Diagnostics
