Sanyo MDF-U5486SC, MDF-U7486SC Cleaning of air intake port, Condition Check / Remedy

Page 23

ROUTINE MAINTENANCE

Cleaning of air intake port

The cap of the left side is turned counterclockwise (Counterclockwise direction), and this product is removed, and the outer air is adopted into the chamber, and it opens a outer door. Therefore, frost is easy to be settled around the air intake port inside the chamber. Clean it in the case shown below.

Condition





Check / Remedy

When frost and ice

can

be

The pipe of the air intake port is thrust with a stick for air intake port

seen in the

port

of

the

air

cleaning of the accessories, and frost is taken.

intake port.



















An outside

door

does

not

The pipe of the air intake port is thrust with a stick for air intake port

open even if the cap of the

cleaning of the accessories, and frost is taken.

air intake port is opened.







Frost and ice can be seen in

Frost inside the chamber and ice are taken with Hera of the

the chamber.









accessories.













Stick for air intake port cleaning (Accessory)

WARNING

For removing the frost of the release port, do not use a tool with sharp edge such as a knife or a screw driver.

- 64 -
