Disposal of Battery

Location of a nickel-metal-hydride battery

This unit is provided a nickel-metal-hydride battery for the power failure warning device. The battery is located in the electrical box inside the cover on the lower left side. (Fig. 1)

The high voltage components are enclosed in the electrical box. The cover should be removed by a qualified engineer or a service personnel only to prevent the electric shock.

Disposal of nickel-metal-hydride battery

1.Turn off the power switch and disconnect the power supply plug.

2.As shown in the Fig. 2, remove 6 screws fixing the side cover with a screw driver and remove the side cover.

3.Remove 5 screws fixing the electrical box cover with a screw driver. (Fig. 3)

4.Disconnect the battery connector and remove 2 screws fixing the battery mounting plate. (Fig. 4)

5.Take out the battery.

6.Follow the procedure for recycling or proper disposal.

		Switch cover
Electrical box	Fig. 1	Side cover	Fig. 2
	Fig. 1
Electrical box cover	Fig. 3
	Fig. 3	Battery	Fig. 4
		mounting plate
25		- 67 -
25
