Model PFE- 590/592

SECTION 3. OPERATION

3-1. OPERATING COMPONENTS

POWER/PUMP Switch A three way switch with center OFF position; move the switch to the position marked POWER to operate the fryer; move the switch to the position marked PUMP to operate the filter pump; certain conditions must be met prior to operation of the filter pump; these conditions are covered later in this section

Frypot

This reservoir holds the cooking shortening, and is designed to



accommodate the heating elements, 8 head of product and an



adequate cold zone for collection of cracklings

Carrier

This stainless steel carrier consists of five racks, containing the food



product during and after frying (4 cook racks and 1 cover rack)

Lid Gasket

Provides the pressure seal for the frypot chamber

Deadweight assembly

The deadweight style operating pressure relief valve is used to



maintain a constant level of steam pressure within the frypot;



any excess steam pressure is vented through the exhaust stack;



remove the deadweight cap, and clean the cap, weight, and



deadweight orifice once a day. See Preventive Maintenance



Section.



Failure to clean the deadweight assembly daily could



result in the fryer building too much pressure. Severe



injuries and burns could result.

Safety Relief Valve

AnASME approved spring loaded valve set at 14.5 psi



(999 mbar); in the event the operation valve becomes obstructed,



this safety valve releases excess pressure, keeping the frypot



chamber at 14.5 psi (999 mbar); if this occurs, turn the COOK/



PUMP switch to the OFF position to release all pressure from the



frypot

If safety relief valve activates, turn main power switch to the OFF position. To avoid serious burns and injuries, have fryer serviced before next use.

3-1
