Henny Penny PFE-592, PFE-590 Troubleshooting Trouble Shooting Guide, Problem Cause Correction

Page 44

Model PFE- 590/592

SECTION 4. TROUBLESHOOTING

4-1. TROUBLE SHOOTING GUIDE



Problem



Cause

Correction



Power switch on but fryer

Open circuit

Fryer plugged in



completely inoperative





• Check breaker or fuse at wall













Pressure not exhausting at

• Solenoid or exhaust line clogged

• Turn off and allow fryer to cool to



end of Cook Cycle





release the pressure in frypot; have











all lines, solenoid and exhaust tank











cleaned













Operating pressure too high

Deadweight clogged

• Turn off and allow fryer to cool to











release the pressure in frypot; clean











deadweight; see Preventive Mainte-











nance Section



DO NOT OPERATE UNIT IF PRESSURE GAUGE SHOWS HIGH PRESSURE CONDITIONS. SEVERE INJURIES AND BURNS WILL RESULT. IMMEDIATELY PLACE THE POWER/ PUMP SWITCH IN THE OFF POSITION, WHICH RELEASES THE PRESSURE BY ALLOW- ING THE UNIT TO COOL. DO NOT RESUME USE OF UNIT UNTIL CAUSE OF HIGH PRESSURE HAS BEEN FOUND AND CORRECTED.

Pressure does not build

Not enough product in frypot

• Place full capacity product in frypot













when using fresh shortening.







Metal shipping spacer not

Remove shipping spacer; see









removed from deadweight assy.



Unpacking Instructions Section







Pressure not programmed

Check programming







Lid gasket leaking

• Reverse or replace lid gasket

















Shortening not heating

Drain valve open

Close drain valve.







• High temperature limit tripped

Reset high temperature limit; see













Operating Components Section















Foaming or boiling over

See Boil-Over chart on fryer

• Follow Boil-Over procedures from









and beginning of Operation



chart









Section in this manual





















Shortening not draining

Drain valve clogged

Push cleaning rod through open













drain valve

















Filter motor won’t run

Motor overheated

Reset motor; see Filter Pump Motor













Protector-Manual Reset Section

















More detailed troubleshooting information is available in the Technical Manual, available at www.hennypenny.com,

or 1-800-417-8405 or 1-937-456-8405.

4-1

703
