Frigidaire FFEF3000MW Model B & C Setting Auxiliary Oven Controls, To Bake, Broil Stop Position

Page 21

MODEL B & C - SETTING AUXILIARY OVEN CONTROLS

TO BAKE

1.Arrange oven racks while the oven is cool.

2.Turn the Temperature Control Knob to the desired oven temperature. When the oven is first turned ON, the oven indicator light below the Temperature Control Knob will glow.

3.Preheat the oven for 10 to 12 minutes before baking. Preheating is not necessary when roasting, cooking casseroles or broiling most foods. When the desired temperature is reached, the oven indicator light will go out. The light will then go ON and OFF as the element cycles ON and OFF to maintain the desired temperature.

4.When cooking is finished, turn the Temperature Control Knob to OFF.

TO BROIL

1.Arrange oven rack while oven is cool. For rare meats, position broiler pan closer to the element (upper position). For well-done foods such as chicken, lobster tails or thick cuts of meat, position the pan further from the element (to a lower position). See table below for recommended position.

Rack Position



From Top

Food

1Rare steaks.

2Ham slices, fish, hamburgers and medium steaks and chops.

3Well-done foods such as chicken and lobster.

2.Turn the Temperature Control Knob to BROIL. To sear rare steaks, allow the element to become red-hot— (about 2 minutes)—before placing food in oven.

3.Place the grid on broiler pan, and then place the meat on the grid (accessories available by mail order). DO NOT use broiler pan without the grid or cover the grid with aluminum foil. The exposed fat could ignite.

4.Place the pan on the oven rack. Close the oven door to the Broil Stop position while broiling (door opened about 2 inches).

5.Broil on one side until food is browned; turn and broil the other side. Season and serve. Note: Always pull the rack out to the stop position before turning or removing food.

6.When broiling is finished, turn the Temperature Control Knob to OFF.

CAUTION

Should an oven fire occur, close the oven door and turn OFF the oven. If the fire continues, throw baking soda on the fire or use a fire extinguisher. DO NOT put water or flour on the fire. Flour may be explosive.

Broil Stop

Position

21
