GE JBP19, JBP20, JBPA48 warranty Problem Possible Cause

Page 33

PROBLEM

POSSIBLE CAUSE







THE DISPLAY GOES BLANK

● Disconnect power to the range at the fuse box or circuit breaker for at least

OR INDICATOR LIGHTS

10 seconds. Turn power on and power up your range. If the indicator lights are

COME ON WHEN THE

still on, call for service.

RANGE IS NOT IN USE









OVEN WILL

● Plug on range is not completely inserted in the electrical outlet.

NOT WORK

● The circuit breaker in your house has been tripped, or a fuse has been blown.









● Oven controls not properly set.





s Door left in locked position after cleaning.











OVEN LIGHT

● Light bulb is loose or defective. Tighten or replace.

DOES NOT WORK

● Switch operating oven light is broken. Call for service.











FOOD DOES NOT

● The Oven Temperature knob not set at BROIL.

BROIL PROPERLY

c Door riot left open to the broil stop position as recommended.









● Improper shelf position being used. See the Broiling Guide.





● Food is being cooked on hot pan.





● Cookware is not suited for broiling.





● Aluminum foil used on the broil pan rack has not been fitted properly





and slit as recommended.







FOOD DOES NOT

. The Oven Temperature knob not set correctly.

ROAST OR BAKE

● Shelf position is incorrect. See the Roasting or Baking sections.

PROPERLY

● Oven shelf not level.









● Incorrect cookware or cookware of improper size is being used.





● A foil tent was not used when needed to slow down browning during roasting.





● Oven thermostat needs adjustment. See the Adjust the Oven Thermostat–





Do 11 Yourself section.







OVEN TEMPERATURE

● Oven thermostat needs adjustment. See the Adjust the Oven Thermostat–

TOO HOT OR TOO COLD

Do It Yourself section.





CLOCK AND TIMER

● Make sure the electrical plug is plugged into a live, properly grounded

DO NOT WORK

power outlet.





● Check for power outage.





● See the Oven Control, Clock and Timer section of this guide.





SURFACE UNITS

● Surface units are not plugged in solidly.

NOT FUNCTIONING

● Drip pans are not set securely in the cooktop.

PROPERLY

@ Surface unit controls are not properly set.











33
